The Ignition Expander module (IEX) is designed to increase the ignition output capacity of MoTeC ECUs.

The IEX connects to a single ignition output on the ECU and can drive up to 8 ignition modules. For 10 and 12 coil applications, two IEX units can be used.

*Note that the IEX does not drive the coil directly, an ignition module is still required.

Compatible with all MoTeC ECUs

Outputs:

  • 8 x ignition outputs
  • Suits most ignition modules of falling edge type
  • The dwell time is controlled by the ECU
  • For 10 and 12 coil applications, two IEX units can be used

Communications:

  • MoTeC specific coded signal supplied from a single ignition output on the ECU

Physical:

  • Case size 70 x 100 x 35 mm
  • Weight 220 gram
  • 18 pin waterproof connector with gold plated contacts

MoTec

MoTec Ignition Expander module (IEX)

SKU M IGN EX
$345.00

The Ignition Expander module (IEX) is designed to increase the ignition output capacity of MoTeC ECUs.

The IEX connects to a single ignition output on the ECU and can drive up to 8 ignition modules. For 10 and 12 coil applications, two IEX units can be used.

*Note that the IEX does not drive the coil directly, an ignition module is still required.

Compatible with all MoTeC ECUs

Outputs:

  • 8 x ignition outputs
  • Suits most ignition modules of falling edge type
  • The dwell time is controlled by the ECU
  • For 10 and 12 coil applications, two IEX units can be used

Communications:

  • MoTeC specific coded signal supplied from a single ignition output on the ECU

Physical:

  • Case size 70 x 100 x 35 mm
  • Weight 220 gram
  • 18 pin waterproof connector with gold plated contacts
$345.00

Product Description

The Ignition Expander module (IEX) is designed to increase the ignition output capacity of MoTeC ECUs.

The IEX connects to a single ignition output on the ECU and can drive up to 8 ignition modules. For 10 and 12 coil applications, two IEX units can be used.

*Note that the IEX does not drive the coil directly, an ignition module is still required.

Compatible with all MoTeC ECUs

Outputs:

  • 8 x ignition outputs
  • Suits most ignition modules of falling edge type
  • The dwell time is controlled by the ECU
  • For 10 and 12 coil applications, two IEX units can be used

Communications:

  • MoTeC specific coded signal supplied from a single ignition output on the ECU

Physical:

  • Case size 70 x 100 x 35 mm
  • Weight 220 gram
  • 18 pin waterproof connector with gold plated contacts
